| Materiaal: | Grade 10 |
| Veiligheidsfactor: | MBL is gelijk aan 4 x WLL |
| Afwerking: | Geverfd blauw |
| Gebruikstemperatuur: | -40°C tot en met +200°C |
| Certificering: | 2.1, 2.2, 3.1, MPIB, DGUV |
| ART.NR | WLL | a | b | c | d | e | f | g | h | i | kg | ||
| mm | inch | t | mm | mm | mm | mm | mm | mm | mm | mm | mm | pc | |
| GPUCSC0601400 | 6 | 7/32 | 1.4 | 75 | 7 | 26 | 15 | 20 | 28 | 72 | 108 | 8 | 0.29 |
| GPUCSC0601950 | 9/32 | 1.95 | 95 | 9 | 30 | 20 | 24 | 32 | 87 | 136 | 10 | 0.58 | |
| GPUCSC0802600 | 8 | 5/16 | 2.6 | 95 | 9 | 30 | 20 | 24 | 32 | 87 | 136 | 10 | 0.58 |
| GPUCSC1004000 | 10 | 3/8 | 4 | 113 | 12 | 33 | 24 | 29 | 42 | 106 | 164 | 13 | 1.11 |
| GPUCSC1306800 | 13 | 1/2 | 6.8 | 138 | 15 | 37 | 32 | 39 | 54 | 133 | 208 | 16 | 2.12 |
| GPUCSC1610300 | 16 | 5/8 | 10.3 | 161 | 19 | 44 | 40 | 44 | 68 | 165 | 240 | 20 | 3.78 |
| GPUCSC2016000 | 20 | 3/4 | 16 | 198 | 22 | 61 | 49 | 62 | 82 | 208 | 305 | 24 | 7.49 |
