| Materiaal: | Grade 8 |
| Veiligheidsfactor: | MBL is gelijk aan 5 x WLL |
| Afwerking: | beugel wit geverfd, pen groen geverfd |
| Gebruikstemperatuur: | -60 C tot en met + 200 C |
| Certificering: | 2.1, 2.2, 3.1, MTCa, CE |
| Opmerking: | geleverd zonder kabels, ontwikkel een eigen kabelplan |
| ART.NR | WLL | a | b | c | d | e | f | g | h | i | j | k | |
| Ton | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | kg/pc | |
| GPP5361D006500 | 6.5 | 22 | 25 | 52 | 22 | 36 | 83 | 58 | 144 | 345 | 102 | 3.5 | 1.50 |
| GPP5361D009500 | 9.5 | 28 | 32 | 66 | 28 | 47 | 108 | 75 | 185 | 381 | 131 | 5.5 | 3.16 |
| GPP5361D012000 | 12 | 32 | 35 | 72 | 32 | 51 | 115 | 83 | 201 | 393 | 147 | 6.5 | 4.31 |
| GPP5361D017000 | 17 | 38 | 42 | 88 | 38 | 60 | 146 | 99 | 249 | 417 | 175 | 8.5 | 7.43 |
| GPP5361D025000 | 25 | 45 | 50 | 103 | 45 | 74 | 178 | 126 | 300 | 464 | 216 | 8.5 | 12.84 |
| GPP5361D035000 | 35 | 50 | 57 | 111 | 50 | 83 | 197 | 138 | 331 | 484 | 238 | 8.5 | 18.15 |
| GPP5361D042500 | 42.5 | 57 | 65 | 130 | 57 | 95 | 222 | 160 | 377 | 516 | 274 | 7.5 | 26.29 |
| GPP5361D055000 | 55 | 65 | 70 | 145 | 65 | 105 | 260 | 180 | 433 | 545 | 310 | 7.5 | 37.60 |
