| Materiaal: | Koolstof en gelegeerd staal |
| Veiligheidsfactor: | MBL is gelijk aan 5 x WLL |
| Standaard: | EN 13155, ASME B30.20-2010 en AS 4991 |
| Afwerking: | Geverfd |
| Gebruikstemperatuur: | -40°C tot en met +100°C |
| Certificering: | 2.1, 2.2, MTCA, CE |
| ART.NR | WLL | a | b | c | d | e | f | g | h | kg | |
| type | t | mm | mm | mm | mm | mm | mm | mm | mm | pc | |
| GPP6616006000 | 6 VE | 6 | 40-90 | 114 | 70 | 486 | 75 | 275 | 78 | 20 | 21 |
| GPP6616007500 | 7.5 VE | 7.5 | 50-100 | 111 | 70 | 524 | 75 | 312 | 86 | 20 | 26.5 |
| GPP6616009000 | 9 VE | 9 | 50-100 | 111 | 70 | 522 | 75 | 312 | 86 | 20 | 27.5 |
| GPP6616012000 | 12 VE | 12 | 50-100 | 152 | 100 | 615 | 85 | 344 | 94 | 44 | 41 |
| GPP6616015000 | 15 VE | 15 | 80-150 | 224 | 136 | 800 | 86 | 450 | 106 | 49 | 76 |
| GPP6616020000 | 20 VE | 20 | 80-150 | 249 | 153 | 924 | 100 | 640 | 140 | 66 | 160 |
